Vacuum box

Product No.:: 90.90.01.00
Shipping time:: 1-2 Weeks (abroad may vary)
Stock:: 1 Stück
Weight:: 110 kg per 1 Stück

Price on request

Ask about product

Vacuum box

Vacuum box for two glue indications, storage of PUR glue indications for several days.

Functionality

Simply put your PUR glue specification in the vacuum container after work and close the flap.

The device then automatically creates and maintains a vacuum.

The glue information can remain in the vacuum container with PUR glue for several days until it is needed again for production.

Technical data

Weight	approx. 110 kg
Outer dimensions	850 x 700 x 550 mm
Inner dimensions	600 x 360 x 360 mm
Type of pump	Vacuum pump
Amount of vacuum	-0,3 Bar
Max. numer of glue applicators	up to 2
Type of control	vacuum is controlled and held electrically
Type of glue	PUR glue

Electrical data

Operating voltage	1 L/N/PE, 230V~
Control voltage	24V DC
Permissible voltage divergence	+/- 10%
Pre-fuse, max.	16A
Frequency range	50/60 Hz
Connected load	max. 0,2 kW
